| Description: |
SPECIAL FLAT COMPOSITE SLOTTED RUPTURE DISC ASSEMBLY WITHOUT FLO-TEL ACTUATOR. RUPTURE DISC GASKETS. CERTIFICATE OF ORIGIN CERTIFIED BY CHAMBER OF COMMERCE. Part number: DSC-FCD- 600-SPECIAL BURST PRESSURE : 0.47 BARG ±0.05 BARG @ 15-30 OC TO ISO4126-2 (2003) MAXIMUM WORKING PRESSURE: : 0.17 BARG @ 15-30 OC BS EN ISO4126-2 (2019) DISC SIZE : 610MM NOMINAL BORE OUTSIDE DIAMETER : 694MM TOP SECTION MATERIAL : AUSTENITIC STAINLESS STEEL SEAL MEMBRANE : FLUOROPOLYMER BOTTOM SECTION MATERIAL : AUSTENITIC STAINLESS STEEL. WITHOUT NON-OPENING VACUUM SUPPORT. TO FIT EHG2 600MM HOLDER FFA : 282743MM2. SEAL ITEM 2 FOR GASKETS PREVIOUS ELFAB DRAWING NUMBER : 02/12/08429 SHT 1 ISS: A 28/02/13, #DSC-FCD- 600-SPECIAL |
