| Description: |
POSITIONER, VALVE: TYPE: ELECTROPNEUMATIC; SUPPLY PRESSURE: 3.5-7 BAR; INPUT: 4-20 MA; MANUF P/N: EL5CD; REFERENCE NO: 6ETG11-12 AA001 MS01; FLOWRATE 3.3 SCFM/93 L/M @ 5.5 BAR; OPERATING TEMPERATURE -20 TO 70 DEG C; CASE AND COVER ZINC ALLOY; SPOOL AND LINER STAINLESS STEEL; ENCLOSURE RATING IP65/NEMA 4X; SENSITIVITY BETTER THAN 0.1MA; HYSTERESIS BETTER THAN 0.7% OF SPAN; REPEATABILITY BETTER THAN 0.7% OF SPAN; ADJUSTMENT LOW AND HIGH POINTS; WEIGHT 2.95KG; DIMENSIONS WD 115 X LG 160 X HT 56MM; TWO WIRE; ANGLE RETRANSMIT; DIN PLUGS, #EL5CD, #6ETG11-12 AA001 MS01 |
