| Description: |
SWITCH,DSCNT:HL121;380 VAC;125 A SWITCH, DISCONNECT: POTENTIAL: 380 VAC CURRENT: 125 A FAULT CURRENT CARRY CAPACITY 20KA FOR 100MS BREAKING CAPACITY AT CURRENT OF 200A 3 POLES PLUS FIXED NEUTRAL TERMINAL SIZE 6-50MM2 TERMINAL TO BE FASTENED WITH ALLEN SCREW ISOLATED WIDTH 107MM HORISONTAL AND 95MM VERTICAL ISOLATER HEIGHT 80MM REMOVABLE SQUARE SHAFT FOR OPERATION SHAFT SIZE 6.5MM X 6.5MM X 200MM ISOLATER ON/OFF SWITCH TO BE LOCKED IN OFF POSITION FRONT PANEL DOOR NOT TO BE ABLE TO OPEN WHEN THE SWITCH IS LOCKED IN OFF POSITION FRONT PANEL DOOR NOT TO BE ABLE TO BE OPENED WHEN SWITCH IS IN THE ON POSITION BLACK ROTARY HANDLE INCLUDED WITH LOCKING FACILITY COMPLETE WITH HANDLES AND SQUARE SHAFT 4 X AUX CONTACTS RATING OF 16A 1 NO 1 NC PART NO: HL121 |
