| Description: |
TRFR:V146.PDF;ACROBAT;22 KVAC;PH 3 TRANSFORMER: TYPE: ACROBAT POTENTIAL: 22 KVAC PHASE: 3 APPARENT POWER: 400 VA 1PH EARTHED CAST RESIN ENCAPSULATED VT WITH 2 LV 63AMP FUSES 1/2A, FITTED INTO A INTERGRATED CR SECONDARY BOX WITH M6 BRASS CONNECTIONS, BRASS GLAND PLATE, MS COVER AND BREATHER, TIN PLATED COPPER EARTH BAR 50 X 6, M24 HV STUD CONNECTION WITH 3 X BRASS HALF NUTS, AND MS BOTTOM MOUNTING PLATE, WEIGHT = 180KG, RATED VOLTAGE = 22000/SQRT, BIL:24/50/150KV, VOLTAGE FACTOR = 2.1 CONT 50HZ, THE VT PARTIAL DISCHARGE IS LIMITED TO 4PC/60SAT 14KV, AFTER A PRE -STRESS OF 19KV/60S, THE VA BURDENS WERE UPF, SEC 1A = 1N=110SQRT3V, 50VA CLASS 3P, SEC 2A-2N=110/SQRT3V, 100VA class 3P AND 1.0, OR 100VA CLASS 0.5 50VA>100VA RANGE PART NO: V146/4W PART NO: V146.PDF |
